The PT12 specifications are outlined, below
| Measurement Ranges: | |||||||
|---|---|---|---|---|---|---|---|
| Temperature | -200 … +660 °C | ||||||
| Resistance | 1 … 380 Ω | ||||||
| Measurement Performance: | For the range of -200 … +250 °C | ||||||
| Resolution | 0.1 mK | ||||||
| Accuracy | ≤ ±2 mK @ 23 °C (95% confidence level, 1 year) | ||||||
| Temperature coefficient | 0.1 mK / °C | ||||||
| Standard Features: | |||||||
| Available inputs | 12 Channels | ||||||
| Input type | Pt-100 and Pt-25 Platinum Resistance Thermometer (PRT), 4-wire, Supports Smart 4-wire PRTs | ||||||
| Supported coefficients | ITS-90, Callendar-Van Dusen | ||||||
| Excitation current | 0.33, 0.66 and 1mA, DC polarity reversing | ||||||
| Reference resistors | 4 internal Ultra High Precision | ||||||
| Data I/O | RS-232, USB (serial port) | ||||||
| Control and data acquisition | RHS Control | ||||||
| Logging intervals | User programmable from 1 seconds to 60 minutes | ||||||
| Sampling rate | <0.5 seconds per channel | ||||||
| Enclosure type | Aluminum | ||||||
| Power supply | External 12VDC power supply with 1.5 m cable (indoor use only) Input:110‐230V, 50/60 Hz, 0.3 A | ||||||
| Operating instructions | English | ||||||
| Factory calibration certificate | Resistance Calibration | ||||||
| Accessories: | |||||||
| Probes | Calibrated and uncalibrated PRT’s available | ||||||
| Connectors | Lemo plug FGG.1B.306 (Optional screw terminals available) | ||||||
| Additional Information: | |||||||
| Maximum operating conditions | 10 … 30 °C, < 98 %RH, non-condensing) | ||||||
| Storage temperature | -20 … +40 °C | ||||||
| Weight and Dimensions: | Instrument only | ||||||
| Dimension (W X H X D) | 200 X 72 X 164 mm | ||||||
| Weight | 1.87 kg | ||||||
To start using the PT12 Precision Thermometer right away, download the manual here and go to page 6, titled “Quick Start / Initial Setup.” There, you’ll find out how to connect a temperature probe, power it up and obtain a reading. We recommend you read through the entire manual to fully understand all of the PT12’s ins and outs, but if you just can’t wait, the quick start section of the manual is, well, a quick start!
RH Systems (RHS) warrants the products it manufactures or distributes to be free of defects in material and workmanship under normal use and service when operated within the specified design limitations for a period of 12 months from date of initial shipment. Under this Warranty, RHS will, at its discretion, repair or replace any component that upon examination by RHS or its duly authorized representatives proves to be defective during the warranty period provided the system is returned to the factory for inspection and repair shipping prepaid. Improper or unauthorized maintenance, storage, repair, or alteration of any kind by personnel other than RHS or its duly authorized representatives may void all warranties. Warranty may also be voided for misuse, neglect, accident, corrosion, and improper installation. This Warranty is exclusive and in lieu of any and all other warranties of merchantability, fitness for a particular purpose, or any other warranty, expressed or implied, and all other liabilities and obligations on the part of RHS. RHS will not be liable for any other claims or damages, either direct, indirect, or consequential arising out of the use of its products.
THERMOtelligent™ Smart-Platinum Resistance Thermometers save you valuable time and decrease the possibility of measurement errors by eliminating the need to change calibration coefficients in the thermometer readout when temperature probes are changed.
Data can be logged automatically to a USB flash drive, or if no drive is detected, data is logged to internal memory and may be copied to a USB drive when inserted at a later time.
Measurements are compensated against drift using four high-precision, high-stability internal reference resistors. During each sampling sequence, the PT12 measures each reference resistor to define the measuring range and accurately determine the unknown values of each of the 12 channels.
